Hyundai Elantra: Battery / Battery capacity label

1. AGM70L-DIN: The HYUNDAI model name of battery

2. 12V : The nominal voltage

3. 70Ah (20HR): The nominal capacity (in Ampere hours)

4. RC 120min: The nominal reserve capacity (in min.)

5. CCA: The cold-test current in amperes by SAE

6. 760A: The cold-test current in amperes by EN

    For Best Battery Service

    Keep the battery securely mounted. Keep the battery top clean and dry. Keep the terminals and connections clean, tight, and coated with petroleum jelly or terminal grease...

    Battery Recharging

    WARNING Always follow these instructions when recharging your vehicle’s battery to avoid the risk of SERIOUS INJURY or DEATH from explosions or acid burns: Before performing maintenance or recharging the battery, turn off all accessories and place the ignition switch to the LOCK/OFF position...
