Hyundai Elantra: Multifunction Switch / Components and components location
Hyundai Elantra (CN7) 2021-2025 Service Manual / Body Electrical System / Multifunction Switch / Components and components location
| Component |
| 1. Steering column 2. Multifunction switch 3. Clock spring | 4. Steering wheel 5. Driver airbag module (DAB) |
Specifications
Specifications
Items
Specifications
Rated voltageDC 12VOperating temperature range-40 to +176°F (-40°C to +80°C)Quantity of standard loadWasherRelated current : 7ABlucking current : 15AInrush current : 20A..
